Curv-O-Mark

SMA radius marker from Curv-O-Mark covering 12 to 20 inch radius range. Scribes accurate arcs and circles on plate and sheet for fabrication layout and template work.

Standard radius marker from Curv-O-Mark covering 12 to 24 inch radius. Used by fabricators and layout workers to scribe arcs and circles for cutting and forming plate.

Jumbo radius marker from Curv-O-Mark spanning 13 to 40 inch radius. Marks large arcs and circles on sheet and plate for tank, pressure vessel, and structural fabrication.

Trammel head set from Curv-O-Mark with Allen wrench and soapstone scribe. Clamps to wood beam to scribe arcs, parallel lines, and circles too large for compass work in plate and sheet metal layout.

Dial-angle flange level from Curv-O-Mark at 20 inch length. Reads pipe and flange angles in degrees for plumb, level, and slope checks in pipefitting and process piping installation.

Magnetic burning guide from Curv-O-Mark at 2 by 24 inch with heat and spatter resistance. Sticks to plate and structural steel as a straight edge for oxy-fuel and plasma cutting in fabrication shops.

Universal level from Curv-O-Mark at 33 inch length with magnetic base. Checks plumb and level on pipe, beams, and structural steel for pipefitters, ironworkers, and welders.

Replacement dial and level assembly from Curv-O-Mark for angle measuring tools. Restores accuracy on dial-angle flange levels after damage in field service or shop use.

Replacement centering pin from Curv-O-Mark for use with centering head tools. Keeps pipe and round stock layout tools functional after pin wear or breakage in fabrication work.
